· RCS-320ODC

32 inch Outdoor Wall Mount LCD Display

This outdoor digital display screen meets the industrial IP65 waterproof and dustproof
rated, equipped with international standard VESA holes for various installations,
ideal for advertising in any outdoor scene. The screen brightness up to 3500 nits,
and the built-in intelligent light sensor ensures a clear and bright display 24/7.
Additionally, the optional capacitive touch providing interactive method for customers.
The metal casing is available in black and white, according to your needs.

Optional Panel Size: 15 inch-86 inch

Request a Quote
Explore features
Scroll
Details on Display

Technical Data

Full Specification

Model No RCS-150ODC RCS-156ODC RCS-185ODC RCS-191ODC RCS-220ODC RCS-240ODC RCS-270ODC RCS-320ODC RCS-430ODC RCS-490ODC RCS-550ODC RCS-650ODC RCS-750ODC RCS-860ODC
Max Resolution 1024×768 1920×1080 1366×768 1440×900 1920×1080 1920×1080 1920×1080 1920×1080 1920×1080 1920×1080 1920×1080 3840×2160 3840×2160 3840×2160
Aspect Ratio 4:3 16:10 16:9 16:10 16:9 16:9 16:9 16:9 16:9 16:9 16:9 16:9 16:9 16:9
Pixel Pitch 0.297×0.297 0.17925×0.17925 0.300×0.300 0.2835×0.2835 0.24795×0.24795 0.2745×0.2745 0.31125×0.31125 0.36375×0.36375 0.4903×0.4903 0.27963x0.27963 0.63×0.63 0.372×0.372 0.429×0.429 0.4935×0.4935
Viewing Angle 80/80/65/80 85/85/85/85 89/89/89/89 85/85/80/80 89/89/89/89 89/89/89/89 89/89/89/89 89/89/89/89 89/89/89/89 89/89/89/89 89/89/89/89 89/89/89/89 89/89/89/89 89/89/89/89
Contrast Ratio 800:1 700:1 1000:1 1000:1 1000:1 1000:1 1000:1 1400:1 1200:1 1200:1 1400:1 1400:1 1200:1 1200:1
Brightness (cd/m²) 2000-3500 2000-3500 2000-3500 2000-3500 2000-3500 2000-3500 2000-3500 2000-3500 2000-3500 2000-3500 2000-3500 2000-3500 2000-3500 2000-3500
Display Area (mm) 304.128x228.096 344.16×193.59 409.8×230.4 408.24×255.15 476.064×267.786 527.04×296.46 597.888×336.312 698.4×392.85 941.184×529.416 1073.78×604 1209.6×680.4 1428.48×803.52 1649.66×927.936 1895.04×1065.96
Panel Size (mm) 326.5×253.5×9.6 359.5×223.8×3.2 430.4×254.6×7.8 428×278×11 495.6×292.2×10.7 543×317.4×11.6 630×368.2×11.8 725.2×422.7×22.4 969×563.9×26 109.5×62.9×29.6 1244.6×720.9×27 1459.2×830×16 1675.2×953.6×11.9 1922.2×1093.2×16.14
